RIFF Box JTAG - original

Enlarge

Price: 171.14 USD

RIFF Box JTAG is a new device from Rocker Team. There are no other device with so many complex functions supported. As always, Rocker team released something unique and outstanding. The devices suits most of user needs, although is aimed at advanced developers who need to debug their own embedded code. (Or reverse someone’s else ). Unique scripting support, GDB Server for IDA real time debugging, Trace32 scripts compatibility and high quality hardware will be on Your service. Our R&D Team is ready to serve our valued customers as well as our tech support staff.

RIFF JTAG firmware supports following features at the moment:

ARM7/ARM9/ARM11 PXA3xx, PXA270, Cortex-A8, OMAP850, Cortex-A9 Dual cores support;
Multiple devices on JTAG chain are supported, thus TAP number selection is available;
Any custom voltage level selection from range ~1.4V to 3.3V
TCK/Adaptive clocking selection
Halt core (NRST is not changed)
Reset core (NRST is applied before halt)
Direct Read memory (by 8/16/32-bit bytes/half-words/words)
Direct Write memory (by 8/16/32-bit bytes/half-words/words)
Access to the control registers of ARM core (coprocessor 15)
Program code breakpoints
Run core
Custom scripting and DCC loader support (trace32 compatible)
Custom GDB Server Available
I/O pins detection !Unique feature offered only by RIFF JTAG

| Currently supported memory controllers are:

OneNAND Memory (connected directly to the MCU’s address space);
CFI Compliant NOR Memory with CFI Command sets 0×0001, 0×0002, 0×0200 and 0×0003;
NAND Controller in MSM6250, MSM6250A;
NAND Controller in QSC6055, QSC6085, QSC6240, QSC6270;
NAND Controller in MDM6085, MDM6200, MDM6600;
NAND Controller in MSM6245, MSM6246, MSM6270, MSM6275, MSM6280, MSM6280A, MSM6281, MSM6290, MSM6800A, MSM6801A;
NAND Controller and OneNAND Controller in MSM7225, MSM7227, MSM7625, MSM7627;
NAND Controller in MSM7200, MSM7200A, MSM7201A, MSM7500, MSM7500A, MSM7501A, MSM7600;
NAND Controller in QSD8250, QSD8650;
eMMC Controller #2 in MSM7230, MSM8255, MSM8255T;
eMMC Controller #0 in S5PV310;

Currently supported chipsets and cores for JTAG I/O operations:

Generic ARM Cores: ARM7, ARM9 (ARM920, ARM926, ARM946), ARM11, CORTEX-A8,CORTEX-A9;
Qualcomm QSC Family: QSC1100, QSC1110, QSC6010, QSC6020, QSC6030, QSC6055, QSC6085, QSC6240, QSC6270;
Qualcomm MSM Family: MSM6000, MSM6150, MSM6245, MSM6246, MSM6250, MSM6250A, MSM6260, MSM6275, MSM6280, MSM6280A, MSM6281, MSM6800A, MSM6801A, MSM6290, MSM7225, MSM7227, MSM7625, MSM7627, MSM7230, MSM8255, MSM8255T, MSM8260;
Qualcomm QSD Family: QSD8250, QSD8650;
Qualcomm ESM Family: ESM7602A;
Qualcomm MDM Family: MDM6085 MDM6200, MDM6600;
OMAP Family: OMAP1710, OMAP3430, OMAP3630, OMAP4430;
NVIDIA Family: TEGRA2;
Marvell/XScale Family: PXA270, PXA271, PXA272, PXA310, PXA312, PXA320.
Samsung Processors: S5P6422, S5PV310.

This is the list of available RIFF JTAG Resurrectors DLL-s , which You can use for one click dead boot repair.
List will be updated with new releases, and this is only small part of models we will add.

Tablets :

Samsung GT-P7320 Galaxy Tab 8.9 LTE Unbrick, Repair, Read/Write eMMC memory
Samsung GT-P6810 Galaxy Tab 7.7 WiFi 16GB Unbrick, Repair, Read/Write eMMC memory
Samsung Galaxy TAB (Samsung P1000) Unbrick, Repair, Read/Write NAND Flash memory
Samsung Galaxy TAB (Samsung P1000N) Unbrick, Repair, Read/Write NAND Flash memory
Samsung Galaxy TAB (Samsung M180s) Unbrick, Repair, Read/Write NAND Flash memory
Samsung Galaxy TAB Wi-Fi (P1010) Unbrick, Repair, Read/Write NAND Flash memory
Samsung Galaxy Note (Samsung N7000) Unbrick, Repair, Read/Write eMMC memory
Samsung Galaxy Note (Samsung i9220) Unbrick, Repair, Read/Write eMMC memory
Samsung Galaxy Plus (GT-P6200) Unbrick, Repair, Read/Write eMMC memory
Samsung YP-G70EW Galaxy S WiFi 5.0 Unbrick, Repair, Read/Write eMMC memory
Samsung GT-P6800 Galaxy Tab 7.7 Unbrick, Repair, Read/Write eMMC memory
Huawei Ideos S7 Unbrick, Repair, Read/Write NAND Flash memory
ZTE V9 Unbrick, Repair, Read/Write NAND Flash memory
HTC EVO View 4G Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Flyer Boot repair, Unlock, CID, ModelID, S-Off, IMEI Update
RIFF JTAG – HTC Flyer WiFi (PG41400) Unbrick, S-off, CID update
Samsung SGH-i717 Galaxy Note LTE Unbrick, Repair, Read/Write NAND Flash memory

GPS Devices:

Daewoo DPN3500 – Boot repair

Mobile phones and communicators :

Alcatel Phones:

Alcatel OT990 - Boot repair/Unbrick

Asus Phones:

ASUS P526 Unbrick/Boot repair

Fly Phones:

Fly IQ285 Unbrick/Boot repair

CoolPad Phones:

CoolPad 5860 + Unbrick/Boot Repair

DELL Phones:

DELL XCD28 Boot Repair/Unbrick
DELL Streak (DELL Mini 5) Boot Repair/Unbrick

Lenovo Phones:

Lenovo LePhone 3G W100 Boot Repair/ Unbrick

Eten Phones:

Eten X800 Boot repair/Unbrick

HTC Phones:

HTC Desire Boot repair/Unbrick, Unlock, IMEI Change/repair CID Change
HTC Diamond Boot repair/Unbrick, Unlock, IMEI Change/repair
HTC Dream – Google G1 Boot repair/Unbrick, Unlock, IMEI Change/repair, Activation bypass
HTC HD2 LEO Boot repair/Unbrick, Unlock, IMEI Change/repair CID Change
HTC Herald Boot repair/Unbrick
HTC Touch P3452 – HTC Elfin – bootloader restore
HTC Magic32A Boot repair/Unbrick, Unlock, IMEI Change/repair
HTC Magic32B Boot repair/Unbrick, Unlock, IMEI Change/repair
HTC Nexus Boot repair/Unbrick, Unlock, IMEI Change/repair
HTC RhodiumW Boot repair/Unbrick, Unlock, IMEI Change/repair
HTC Rhodium Touch Pro2 Boot repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Topaz Boot repair/Unbrick, Unlock, IMEI Change/repair
HTC Touch HD Boot repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Touch2 Mega Boot repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Imagio/Whitestone repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Snap – Maple 120, Maple 100repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Dash repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Tattoo Click 100 Boot repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Niki (HTC Touch Dual) Boot repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Kovalsky Boot repair/Unbrick, Unlock, IMEI Change/repair, CID Change
HTC Jade (HTC Touch 3G T3232) Unbrick/Boot Repair, Unlock, IMEI Change/repair, CID Change
HTC Legend Unbrick/Boot Repair, Unlock, IMEI Change/repair, CID Change
HTC Wildfire Unbrick/Boot Repair, Unlock, IMEI Change/repair, CID Change
HTC Hero Unbrick/Boot Repair, Unlock, IMEI Change/Repair, CID Change
HTC Wings (HTC S730 US) Boot Repair, IMEI Change, CID Change
HTC HD7 Boot Repair, IMEI Change, CID Update, Network Unlock
HTC Gene-P3400 (Gene100) Boot repair/Unbrick
HTC Artemis (ARTE100, ARTE110) Boot repair/Unbrick
HTC Click 1100 (ESM7225 Asia version) Boot Repair, IMEI Change, CID Update, Network Unlock
HTC Ozone XV6175 (HTC Chief) Boot Repair, IMEI Change, CID Update, Network Unlock
HTC Advantage X7510 (HTC Athena) Boot Repair / Read-Write MDOC
HTC 7 Mozart Unbrick, Unlock, IMEI Repair, CID Repair, ModelID Repair
HTC Polaris (HTC Touch Cruise P3650) Unbrick, Unlock, IMEI Repair, CID Repair, ModelID Repair
HTC 7 Trophy (HTC Spark) Unbrick, Unlock, IMEI Repair, CID Repair, ModelID Repair
Dopod Magic A6188 (HTC Sapp400) Unbrick, Unlock, IMEI and CID repair
HTC Desire HD SPL Repair (Unbrick), IMEI Repair, Unlock, CID and ModelID update
HTC Wildfire S SPL Repair (Unbrick), IMEI Repair, Unlock, CID and ModelID update
HTC Universal (PU10) Unbrick/Boot repair
HTC Wizard 200 (MDA Vario, QTEK9100, SPV M3000 . . .) Ubrick/Boot Repair
HTC Desire S (HTC Saga) Unbrick, Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Desire Z (HTC Vision) Unbrick, Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Incredible S Unbrick, Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Inspire 4G A9192 (HTC Stallion) Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Panache/Glacier/My Touch 4G Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Droid Incredible 2 ADR6350 Boot repair, Unlock, CID, ModelID, IMEI Update
HTC ThunderBolt 4G ADR6400 (HTC Mecha) Boot repair, Unlock *, CID, ModelID, IMEI Update
HTC Touch Dual US (HTC Neon 300/200) Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Sensation (HTC Pyramid) Unbrick, Unlock, ModelID, CID, S-Off, IMEI repair
HTC EVO 3D (HTC Shooter) Unbrick, Unlock, ModelID, CID, S-Off, IMEI repair
HTC EVO View 4G Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Sensation XL X315 / Bass (HTC Runnymede) Boot repair, Unlock, CID, ModelID, IMEI Update, S-Off
HTC 7 Pro (HTC Gold) Boot repair, Unlock, CID, ModelID, S-Off, IMEI Update
HTC 7 Surround T8788 (HTC Mondrian) Boot repair, Unlock, CID, ModelID, S-Off, IMEI Update
HTC One V T320e (HTC Primo) Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Radar (HTC Omega) Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Rhyme (HTC Bliss) Boot repair, Unlock, CID, ModelID, IMEI Update
HTC Sensation XE PG5813001 (G18) Boot repair, Unlock, CID, ModelID, IMEI Update, S-Off
HTC Explorer (HTC Pico) Unbrick, Unlock, SuperCID IMEI repair
HTC ChaCha A810e Unbrick, Unlock, SuperCID IMEI repair
T-Mobile myTouch2 3G Slide (HTC Espresso) Unbrick, Unlock, SuperCID IMEI repair
HTC Flyer 4G P515E Unbrick, SuperCID, IMEI repair
HTC Wildfire S CDMA (HTC Marvel C) Unbrick, SuperCID, IMEI repair

Huawei Phones:

Huawei Ideos X1 U8180 (Huawei Gaga) Unbrick, Dead Boot repair
Huawei U8110 Unbrick, Dead Boot repair
Huawei U8800 Impulse 4G/ X5 Unbrick, Dead Boot repair
Huawei 1280 Unbrick, Dead Boot repair
Huawei C8500 Unbrick, Dead Boot repair

LG Phones:

LG GT540 Optimus Unbrick/Boot Repair
LG P500 Optimus One Unbrick/Boot Repair
LG CU720 Shine Unbrick/Boot Repair
LG SH860 Unbrick/Boot Repair
LG P350 Unbrick/Boot Repair
LG P698 Optimus Link Unbrick/Boot Repair
LG P705 Optimus L7 / P700 Unbrick/Boot Repair
LG P970 Optimus Unbrick/Boot Repair
LG C660 Optimus Pro Unbrick/Boot Repair
LG F-160K Optimus LTE2 Unbrick/Boot Repair
LG F-160L Optimus LTE2 Unbrick/Boot Repair
LG F-160S Optimus LTE2 Unbrick/Boot Repair

HP Phones:

Hewlett-Packard iPAQ 614Unbrick/Boot repair

Pantech Sky Phones:

Pantech Sky Vega LTE EX IM-A820L Unbrick/Boot repair
Pantech Sky Vega LTE IM-A800s Unbrick/Boot repair
Pantech SKY Vega RACER IM-A760S Unbrick/Boot repair
Pantech Sky Vega T100K Unbrick/Boot repair

SonyEricsson Phones:

SE Xperia X1 Boot repair/Unbrick, Unlock, IMEI Change/repair, CID Change
SE Xperia X10 Boot repair/Unbrick Unlock, IMEI Change/repair
SE Xperia X10 Mini Boot repair/Unbrick Unlock, IMEI Change/repair
SE Xperia E10 Boot repair/Unbrick Unlock, IMEI Change/repair
SE Xperia X8 Boot repair/Unbrick Unlock, IMEI Change/repair
SE Xperia E15 Boot repair/Unbrick Unlock, IMEI Change/repair

Samsung Phones:

Samsung B7330 Boot Repair/Unbrick
Samsung C5510 Boot Repair/Unbrick
Samsung F480 Boot Repair/Unbrick
Samsung F500 modem Boot Repair/Unbrick
Samsung G810 modem Boot Repair/Unbrick
Samsung G810 PDA Boot Repair/Unbrick
Samsung i450 modem Boot Repair/Unbrick
Samsung i450 PDA Boot Repair/Unbrick
Samsung i550 modem Boot Repair/Unbrick
Samsung i550 PDA Boot Repair/Unbrick
Samsung i560 PDA Boot Repair/Unbrick
Samsung i568 PDA Boot Repair/Unbrick
Samsung i560 modem Boot Repair/Unbrick
Samsung i568 modem Boot Repair/Unbrick
Samsung i5500 Galaxy Boot Repair/Unbrick
Samsung i5510 Galaxy Boot Repair/Unbrick
Samsung I5700 Boot Repair/Unbrick
Samsung i5800 Boot Repair/Unbrick
Samsung i710 Boot Repair/Unbrick
Samsung i718 Boot Repair/Unbrick
Samsung i740 PDA Boot Repair/Unbrick
Samsung i740 Modem Boot Repair/Unbrick
Samsung I7500 Boot Repair/Unbrick
Samsung i780 modem Boot Repair/Unbrick
Samsung i780 PDA Boot Repair/Unbrick
Samsung i897 Captivate Boot Repair/Unbrick
Samsung I8000 Boot Repair/Unbrick
Samsung i8320 modem Boot Repair/Unbrick
Samsung i8320 PDA Boot Repair/Unbrick
Samsung i8510 modem Boot Repair/Unbrick
Samsung i8510 PDA Boot Repair/Unbrick
Samsung i8910 modem Boot Repair/Unbrick
Samsung i8910 PDA Boot Repair/Unbrick
Samsung I9000 Boot Repair/Unbrick
Samsung i900 modem Boot Repair/Unbrick
Samsung i900 PDA Boot Repair/Unbrick
Samsung i908E modem Boot Repair/Unbrick
Samsung M7500 Boot Repair/Unbrick
Samsung M7600 Boot Repair/Unbrick
Samsung M8910 Boot Repair/Unbrick
Samsung S3310 Boot Repair/Unbrick
Samsung S3370 Boot Repair/Unbrick
Samsung S5230 Boot Repair/Unbrick
Samsung S5510 Boot Repair/Unbrick
Samsung S5560 Boot Repair/Unbrick
Samsung S5560i Boot Repair/Unbrick
Samsung S5570 Boot Repair/Unbrick
Samsung S5600 Boot Repair/Unbrick
Samsung S5660 Boot Repair/Unbrick
Samsung S7070 Boot Repair/Unbrick
Samsung S7230E Wave 723 Boot Repair/Unbrick
Samsung S7350 Boot Repair/Unbrick
Samsung S7350i Boot Repair/Unbrick
Samsung S8000 Boot Repair/Unbrick
Samsung S8300 Boot Repair/Unbrick
Samsung S8500 Boot Repair/Unbrick
Samsung T919 Boot Repair/Unbrick
Samsung T669 Boot Repair/Unbrick
Samsung T959 Boot Repair/Unbrick
Samsung U700 Boot Repair/Unbrick
Samsung U800 Boot Repair/Unbrick
Samsung U900V Boot Repair/Unbrick
Samsung Z240 Boot Repair/Unbrick
Samsung Z540 Boot Repair/Unbrick
Samsung G800 Boot Repair/Unbrick
Samsung i607 PDA Boot Repair/Unbrick
Samsung Galaxy Mini (S5570) Boot repair/Unbrick
Samsung Nexus S (Samsung i9023) Boot repair/Unbrick
Samsung Eternity A867 Boot repair/Unbrick
Samsung Galaxy Ace S5830 Boot repair/Unbrick
Samsung Z630 Boot repair/Unbrick
Samsung Galaxy S 4G (T959v 1GB) Boot repair/ Unbrick
Samsung T749 Boot repair / Unbrick
Samsung GT-i8700 Omnia 7 Boot repair / Unbrick
Samsung W299 Boot repair / Unbrick
Samsung P960 Boot repair / Unbrick
Samsung Galaxy S II Boot repair / Unbrick
Samsung A837 Boot repair / Unbrick
Samsung Anycall m110s Boot repair / Unbrick
Samsung Wave II (S8530) Boot repair / Unbrick
Samsung s7330 Boot repair / Unbrick
Samsung Focus – i917 Boot repair / Unbrick
Samsung i997 Boot repair / Unbrick
Samsung Galaxy II OMAP4430 (i9100G, i9108)
Samsung Corby II (S3850) Boot repair / Unbrick
Samsung i520 Modem and PDA parts Boot repair / Unbrick
Samsung z500 Boot repair / Unbrick
Samsung Galaxy S Plus (Samsung i9001) Boot repair / Unbrick
Samsung Galaxy SL (Samsung i9003) Boot repair / Unbrick
Samsung Galaxy Prevail (Samsung m820) Boot repair / Unbrick
Samsung Star Duos (C6712) Boot repair / Unbrick
Samsung GT-i9103 Galaxy Z / Galaxy R Boot repair / Unbrick
Samsung GT-S5670 Galaxy Fit Boot repair / Unbrick
Samsung SGH-T759 Exhibit 4G Boot repair / Unbrick
Samsung GT-i8150 Galaxy W (Samsung Ancora) Boot repair / Unbrick
Samsung Galaxy Precedent SCH-M828 Boot repair / Unbrick
Samsung SGH-i777 Galaxy S II Boot repair / Unbrick
Samsung GT-S7500 Galaxy Ace Plus Boot repair / Unbrick
Samsung S8600 Wave 3 Boot repair / Unbrick
Samsung GT-S5360 Galaxy Y Boot repair / Unbrick
Samsung SGH-T499 Dart (Samsung Tass) Boot repair / Unbrick
Samsung SGH-T989 Galaxy S II
Boot repair / Unbrick
Samsung SGH-i727 Galaxy S II Skyrocket Boot repair / Unbrick
Samsung SCH-I500 Galaxy S Mesmerize/Fascinate Boot repair / Unbrick
Samsung SHV-E120S Galaxy S II HD LTE (Samsung Celox) Boot repair / Unbrick
Samsung SCH-i920 Omnia II 8GB Boot repair / Unbrick
Samsung Galaxy Mini – GT-S5570i Boot repair / Unbrick
Samsung Galaxy Ace – GT-S5830i Boot repair / Unbrick
Samsung Z650i Boot repair / Unbrick
Samsung SGH-T679 Exhibit II 4G (Samsung Ancora) Boot repair / Unbrick
Samsung SPH-D710 Galaxy S2 Epic Touch 4G Boot repair / Unbrick
Samsung SHV-E160K Galaxy Note LTE Boot repair / Unbrick
Samsung SGH-i747 Galaxy S III LTE Boot repair / Unbrick
Samsung SGH-A887 Boot repair / Unbrick
Samsung SHV-E120L Galaxy S II HD Boot repair / Unbrick
Samsung SHV-E160L Galaxy Note LTE Boot repair / Unbrick
Samsung GT-S6102 Galaxy Y Duos Boot repair / Unbrick
Samsung GT-S7500L Galaxy Ace Plus Boot repair / Unbrick
Samsung GT-B7510 Galaxy Pro Boot repair / Unbrick
Samsung GT-B5510 Galaxy Y Pro / Galaxy Txt Boot repair / Unbrick
Samsung GT-B5620 OmniaPRO 5 / GT-B6520 Omnia 652 Boot repair / Unbrick
Samsung SGH-P960 Boot repair / Unbrick
Samsung GT-S7250D Wave M Boot repair / Unbrick
Samsung SGH-i747M Galaxy S III LTE Boot repair / Unbrick
Samsung SGH-T999V Galaxy S 3
Samsung SGH-T999 Galaxy S 3
Samsung GT-S5830G Galaxy Ace Boot repair / Unbrick
Samsung GT-S6500 Galaxy Mini 2 (Samsung Jena) Boot Repair – Unbrick
Samsung Galaxy K SHW-M130K Boot Repair – Unbrick
Samsung SGH-L760 Boot Repair – Unbrick
Samsung GT-S5380D Wave Y Boot Repair – Unbrick
Samsung GT-i9070 Galaxy S Advance Boot Repair – Unbrick
Samsung GT-i8160 Galaxy Ace 2 Boot Repair – Unbrick
Samsung GT-S5300 Galaxy Pocket Boot Repair – Unbrick
Samsung GT-S5830L Galaxy Ace Boot Repair – Unbrick
Samsung GT-T589 Boot Repair – Unbrick
Samsung ZV60 Boot Repair – Unbrick
Samsung GT-S6802 Galaxy Ace Duos Boot Repair – Unbrick

Toshiba Phones:

Toshiba G810 Boot Repair/Unbrick
Toshiba G900 Boot Repair/Unbrick
Toshiba G910 Boot Repair/Unbrick
Toshiba TG01 Boot Repair/Unbrick, EFS rebuild, Unlock (IMEI will be changed)

ZTE Phones:
